Abstract: Over the past few years, organic electronics - and especially organic mixed ionic electronic conductors (OMIECs) - has taken bio sensing and neuromorphic applications to a whole new level. However, one of the major limitations of the mainstream technolog ies today is that electronic circuits need to be pre-shaped according to the intended use and the expected outcome. This top-down approach, far from being flexible/adaptive, does not really make the most of the resources at hand, as it is hard to predict precisely where cells will be located. To counter that, we can either choose to increase the density and the number of electrodes, so that the entire area would be mapped, or shift from a top-down to a bottom-up approach which would allow for a more enl ightened decision-making process. Recently, the electrodeposition of PEDOT:PSS has been explored as a novel technique to grow conducting polymer films and fibers on non-conductive substrates. The work of Janzakova and coworkers took that concept a step f urther by using electropolymerization of EDOT as a way to create freestanding dendritic-like conductive fibers in a 3D environment, paving the way for in operando material modification, and in fine bottom-up fabrication routes that would be more adaptive and allow for more flexibility. Moreover, it was lately showed that these objects could work as Organic Electrochemical Transistors (OECTs). Here, we explore the possibility of growing dendritic-like PEDOT fibers on Multielectrode Arrays (MEAs) via elec tropolymerization of EDOT. Electrophysiological measurements are based on the capacitive coupling between cells and the electrode material. In comparison with local electrodes, the dendritic objects present spatially distributed impedance due to the exte nsions of their dendritic branches interacting with the biological environment. We investigate the relation between morphology and impedance in these dendritic-like fibers by using a non-conventional Electrochemical Impedance Spectroscopy (EIS) setup tha t will allow us to apply a potential difference between the two ends of the dendrites, thus studying how biasing them can affect their behavior. Moreover, it appears that dendritic fibers can be considered both as passive electrodes as well as active dev ices. We explore the use of these two strategies in the context of electrophysiological measurements. Finally, the ability to record biological signals results from the interaction between cells and an electrode. Unconventional objects such as dendrites present spatio-temporal filtering properties that could affect the recording of such signals. We investigate how tuning the impedance of a dendrite might be used to record efficiently bio-signals.

Abstract: The development of electronic devices for neurosensing is leading to fundamental discoveries in communication setups for interfacing and computing the brain's electrical activity that is still a demanding task in the 21st century. One of the greatest cha llenges for efficient neurosensing is to ensure that detection/transduction between biochemically rich systems and tools is fully mastered to reliably gather relevant information. In extracellular devices such as microelectrode arrays (MEAs), the discord ance lies at the interface between ions and the electrodes. Engineering chemically/morphologically the electrode's materials by decreasing its impedance, improving its affinity with neurons, and boosting its biocompatibility ensures better cell/electrode interface conditions to find the right materials that detect ionic signals from neurons and transduce them into electronic signals with the lowest information loss. Hence, the use of conducting polymers (PEDOT) has emerged for optimizing the performance of microelectrodes in neurosensing due to its mixed ionic electronic conduction, biocompatibility and low impedance. In parallel to the development of passive microelectrode, organic electrochemical transistors (OECTs) have received lots of attention in the biosensing field since they exhibit high coupling with cells and signal amplification. Notably, the transconductance represents an important parameter that depends on geometrical and material parameters that rules largely OECTs performances in biose nsing. In this direction, we explore the use of EDOT electropolymerization to tune post-fabrication material and geometrical parameters of passive microelectrodes for optimizing the cell/electrode interface by decreasing its impedance and improving its a ffinity with neurons (increasing the resistance "Rseal" that represents the cell/electrode cleft). For electropolymerized PEDOT MEAs, we demonstrate long term and stable extracellular recording of primary cortical neurons with a record signal-to-noise ra tio (SNR) up to 37 dB (with ultra-low noise down to 2.1 μV RMS). Secondly, for active sensing with OECTs, this strategy exploits the concept of adaptive sensing where both transconductance and impedance are tuned simultaneously or independently. This approach shows an improvement of OECTs transconductance by 150-percent, volumetric capacitance by 300-percent, and a reduction in array's variability by 60-percent in comparison with standard spin-coated OECTs. The cytotoxicity of the electropolymerized EDOT was assessed for primary neural cells culture and no detrimental effect of electropolymerized EDOT on cell viability was observed. To extract the impedance and transconductance values for both MEAs and OECTs, we combine DC electrical measurements w ith electrochemical impedance spectroscopy (EIS). To show the cell/electrode morphology and neurite outgrowth to electropolymerized microelectrodes, Scanning Electron Microscopy (SEM) was performed. To correlate the morphological changes of the material with the enhancement of its electrical and electrochemical performances, Atomic Force Microscopy (AFM) in liquid and Raman Spectroscopy were achieved. Finally, in-vitro extracellular recorded signals from entorhinal cortex cultured slices and primary cor tical neurons using both MEAs and OECTs are presented. The key novelty of this technique is to propose a post-fabrication material engineering technique that can be used to optimize both passive (MEAs) and active (OECTs) devices for extracellular recordi ng and promote new exploratory sensing strategies to ensure high quality neurosensing alternatives.
